Name: Six Shafts Type Automatic Aluminum Foil / Cling Film Rewinder(AH-6SP)
Brand: Tru Brite Machinery Co., Ltd

Six Shafts Type Automatic Aluminum Foil / Cling Film Rewinder(AH-6SP)

классификация: Автоматическая перемотка алюминиевой фольги/пищевой пленки

Applications: Стаканы, лотки и упаковка для общепита Бумажные стаканы и пищевая бумага

Tru Brite Machinery Co., Ltd

Страна: Taiwan

Телефон: 886-3-9906271

факс: 886-3-9906651

Контактное лицо: Min Rong Wu

Запрос сейчас

AH-6S, the six shaft type automatic rewinding machine.
It's designed for rewind aluminum, PE and PVC cling film.
The feeding press roller is carried with precise pressure manometer and regulating valve.
Movements include automatic feeding material, automatic cutting and unloading the finished product.
This model has automatic length correcting function. It can correct the margin of product length anytime.
There are 2 type of mother roll width for AH-6S: from 250-450 mm, and from 300-500 mm.
The product length is from 3-250 meters, the finished paper core’s I.D. can be appointed within 25-38 mm.
Users can choose to equip label sticker device and hot melt glue device with machine.
They will make product more perfect.
Stably fix the material on the paper core, neatly produce product with smooth edge.
Machine brings you a huge benefit in the way you need.
Welcome to consult machine with us. We will at your service.

Finished Product End Processing Conveyor System

The AH-CS Finished Product End Processing Conveyor System is an optional module designed to work with all Tru-Brite rewinder machines. It performs end-of-roll processing such as labeling, sealing, and wrapping after the rewinding process. Featuring an independent operating system, it can be used as a standalone unit or integrated into existing production lines, effectively improving productivity, reducing manual labor, and enhancing overall production stability.

Independent Conveyor Processing System: Can operate independently and be flexibly integrated with different machine models.
Label Sticker Mode: Supports both long and short labels with automatic application on the end of finished rolls.
Label Paper Mode: Applies printed label paper with logo or product information and wraps the roll end securely.
Automatic Edge Detection: Detects the roll edge position automatically to ensure accurate label placement.
Stepper Motor Control: Provides precise positioning and speed control for stable and consistent operation.
Customizable Design: Can be tailored according to factory layout and production capacity requirements.

Model	AH-6S(250-450)	AH-6S(300-500)
Raw Material	Aluminum foil / PE.PVC food wrapping film
Capacity (On the basis of foil roll’s length within 10 meters)	30rolls/min
Mother roll core inner diameter (I.D.)	3” (76 mm)/6"(152mm)
Max mother roll diameter	700 mm
Mother roll available width	250 - 450 mm	300 - 500 mm
Material thickness	9 - 20 micron
Length of the finished rolls	3 - 250 Meter
Max finished roll's diameter	80 mm
Finished paper core Length	255 - 470 mm	305 - 520 mm
Max finished roll's paper core diameter	50mm
Finished paper cores inner diameter (I.D.)	25 - 38 mm
Pressure of compressed air system	8±2atm
power supply	AC220/380/415/440V,50Hz/60Hz,3PH
Max power consumption	7.0 KW(no glue) 11kw(glue)
Dimensions L x W x H	2450 x 2100 x 2000 mm
Net weight	2100 kg

The AH-6SP fully automatic 6-shaft dual-purpose rewinding machine features upgraded cutting and rewinding control systems. Settings can be flexibly adjusted according to different materials and finished product requirements. It is suitable for high-efficiency rewinding processes of aluminum foil, PE film, PVC film, and cling film, helping users increase capacity, stabilize product quality, and optimize the overall production process.

Upgraded Cutting System: The cutting blades feature a flat-edge design, making them ideal for cutting aluminum foil. The more efficient cutting action boosts cutting speed and finished roll output.
Improved Core Slot Design: Two new pneumatic cylinders have been added to facilitate stable loading of paper cores onto the chucks. Operation is smoother when transferring cores to the rewinding shaft, ensuring firmer chuck clamping.
Dedicated Motor for Post-Cut Speed Control: Speeds for the "rewinding in progress" and "completed but not yet unloaded" sections can be configured independently, improving conveying stability for large-diameter finished rolls.
Fully Automatic Operation: Built-in automatic loading, cutting, and unloading features reduce manual labor requirements, enhancing line stability and production efficiency.
Precise Pressure Control: The feeding press roller is equipped with a precision pressure gauge and regulating valve to ensure uniform material tension and improve finished product quality.
Automatic Length Correction: Features a built-in automatic error correction function that adjusts finished product length in real time, reducing deviation and ensuring precise product specifications.
Suitable for Various Parent Roll Dimensions:
- Parent roll width: 250–450 mm / 300–500 mm
- Finished core inner diameter range: 25–38 mm
Optional Equipment: Can be paired with a labeling machine and glue sprayer to enhance complete product processing.
Optional Systems: This system can operate independently with any model to handle end-of-line processing, effectively improving production efficiency and reducing labor load.
Independent Conveyor Operation: The conveyor belt can operate independently to support aluminum foil tail-end labeling or label applicator functions, improving downstream packaging integration efficiency.
Labeling Machine Mode: Supports long or short label selection; automatically detects gaps, corrects positioning, and applies labels.
Label Applicator Mode: Applies labels directly onto the surface of aluminum foil rolls and can be integrated with hot-melt glue equipment to wrap and secure the label paper.
