Name: Машина для резки небольших этикеток-ACDV-30MS
Brand: DAH BAH MACHINERY INDUSTRIAL INC.

классификация: Машина для производства термоусадочной пленки ПВХ

DAH BAH MACHINERY INDUSTRIAL INC.

Страна: Taiwan

Телефон: 886-4-24832477

факс: 886-4-24830852

Контактное лицо: Angela Chi

Запрос сейчас

Materials

Main Power

Unwinding Section

Coreless unwind stand saves paper core costs.
Equipped with feeding motor and position detector to provide more stable tension before material cutting.

Perforation Device

Equipped with two types of perforation knives: circular and straight perforation knives, capable of performing perforations in two different directions simultaneously. Combined with special cutters, it can cut various types of labels.

Cutting Section

Equipped with feeding servo motor, machine speed can be significantly increased up to 400 cuts/min. (for cutting lengths under 50mm), and cutting accuracy is also more precise.
Equipped with German photoelectric eye device to control precise cutting position.

Model No.		ACDV-30S	ACDV-50S
Max. Parent Web Width		300 mm	500 mm
Max. Parent Web Diameter		800 mm	800 mm
Max. Cutting Length	Plain film	400 mm	500 mm
Max. Cutting Length	Printed Film	300 mm	400 mm
Max. Machine Speed		400 Cuts / min.	300 Cuts / min.
Installation Information (For Standard Specification)	Net Weight	600 kg	1100 kg
	Area Required	L2395 x W1066 x H1415 (mm)	L2500 x W1310 x H1420 (mm)
	Power	380V / 3.6KW / 13A	380V / 3.6KW / 13A
	Water	X	X
	Air	6 kg / cm3	6 kg / cm3
