Single-Layer High-Speed Blown Film Machine

классификация: Линия выдувной пленки

Applications: сельское хозяйство Сельскохозяйственные фильмы Фермерские фильмы Сельскохозяйственные пленки PE

KUNG HSING PLASTIC MACHINERY CO., LTD.

Страна: Тайвань

Телефон: 886-5-2374466

факс: 886-5-2376971 /886-5-2381029

Контактное лицо: Kun Lin Tsai

Запрос сейчас

Materials & Applications

Suitable Materials: LDPE, LLDPE (recycled materials)
End-Use Application:
- Agricultural films (e.g., covering films, protection films)

The single-layer configuration maximizes recycled material usage while maintaining a simple, efficient production process—ideal for cost-sensitive agricultural markets.

Production Range & Output Performance

Film Width: 3000 mm
Film Thickness Range: 75 – 150 microns
Maximum Extrusion Output: 850 kg/hr
Die Head Diameter: Ø950 mm
Extruder Screw Diameter: Ø 150mm

Cooling & Width Control System

Dr. Joseph IBC (Internal Bubble Cooling) System with Width Control
Enhances cooling efficiency and stabilizes bubble geometry and frost line height, ensuring uniform film thickness and consistent width during high-speed, high-output operation with recycled materials.

Material Handling & Extrusion Control

Doteco Gravimetric Dosing System with Extrusion Control and Material Conveying

Take-Up Unit: Horizontal upper oscillating system

Key Advantages

Single-layer, high-speed design optimized for agricultural film production
Supports LD / LLDPE recycled materials for cost efficiency and sustainability
Ultra-wide 3000 mm film width with output up to 850 kg/hr
IBC cooling with width control ensures stable film formation at high speeds
Simple structure, easy maintenance, and suitability for long-term continuous operation
