Name: V Series (Vertical Toggle System)
Brand: LAUNCH MACHINERY WORKS CO., LTD.

классификация: Injection Molding Machine

LAUNCH MACHINERY WORKS CO., LTD.

Страна: Taiwan

Телефон: 886-2-22980855

факс: 886-2-22980655

Контактное лицо: Mr. Xu

Запрос сейчас

Machine Features: All Machine parts and equipments are guaranteed to be imported from Europe, USA and Japan.

Stationery Platen and Movable Plated

All plated is through analysis by CAE technology to minimizing platen warping and ensure trigh rigidify for mold platen.

Toggle features

Five point slant toggle mechanism structure with high harden steel material to ensure toggle mechanism stronger and extend toggle life.

Mold Clamping with breaking system and mold adjustment gear type system.

After auto mold adjustment is complete, the clutch of breaking system is interlock for the mold adjustment system to prevent mold clamping force unstability and make sure product diamension make lasting.

Tie Bar

Tie Bar uses pre-tensioned design to promote durability and increase stronger and decrese tie bar broken.

Screw Charging Stand

Injection unit uses double cylinder injection design to ensure stably and stronger injection pressure.

Nozzle Stand

Nozzle Stand uses "T" shape sloted design to ensure high rigidy and stable. No need to move the nozzle stand in order to change barrel.

Machine Base

All machine base are using solid steel welding with support bar design for stronger and rigrdy machine base.

VERTICAL TOGGLE MODEL OF VERTICAL
LCH-VXX-A-B
ITEM			MODEL	LCH-V100			LCH-V140			LCH-V180			LCH-V260			LCH-V320
射出部份	INJECTION UNIT
螺旋桿直徑	Screw Diameter		mm	S	M	L	S	M	L	S	M	L	S	M	L	S	M	L
				32	36	40	36	40	45	40	45	50	50	55	60	60	65	70
射出壓力	Injection Pressure		kg/cm 2	2052	1621	1313	2074	1680	1327	2218	1753	1420	2047	1691	1421	1867	1591	1371
射出率 Injection Rate		一般 General	cm 3 /sec.	65	83	102	82	101	127	97	122	151	131	159	189	158	186	215
		快速 High Speed		125	159	196	158	194	246	184	233	288	219	266	316	350	411	476
理論射出容積	Theoretic Shot Volume		gr	129	163	201	163	201	254	251	318	393	393	475	565	848	995	1154
射出重量 (PS)	Injection Weight (PS)		gr	116	146	181	146	181	229	226	286	353	353	427	509	763	895	1039
			oz	4.1	5.1	6.3	5.1	6.3	8.0	7.9	10	12	12	15	18	27	31	36
鎖模部份	CLAMPING UNIT		上下肘節 VERTICAL TOGGLE
鎖模力	Clamping Force		Ton	100			140			180			260			320
開模行程	Clamping Stroke		mm	300			330			390			450			510
脫模行程	Ejector Stroke		mm	100			100			130			150			150
支柱內距	Space Between Tie Bar		mm	360 × 360			410 × 410			460 × 460			510 × 510			560 ×560
夾模厚度	Mold Thickness		mm	100-400			120-450			150-520			180-600			200-700
動力部份	POWER UNIT
電機馬達 Pump Motor		一般 General	HP(KW)	15(11)			20(15)			25(18.5)			30(22)			40(30)
		快速 High Speed		25(18.5)			30(22)			40(30)			50(37)			60(45)
電熱容量	Heater Capacity		KW	6.3			6.9			8.8			10.6			14.2
泵浦壓力	Pump Pressure		kg/cm 2	140			140			140			140			140
溫度控制	Thermo Control		point	4			4			4			4			5
寸法	MEASUREMENTS
機械尺寸	Machine Size (L×W×H)		m	4.0×1.2×1.7			4.2×1.3×1.8			5.0×1.4×1.9			5.4×1.5×2.0			6.3×1.75×2.1
機械重量	Machine Weight		kg	3400			4250			6100			8300			11500
油箱容量	Tank Capacity		l	175			200			390			450			650

ITEM			MODEL	LCH-V420			LCH-V480			LCH-V550			LCH-V750			LCH-V850
射出部份	INJECTION UNIT
螺旋桿直徑	Screw Diameter		mm	S	M	L	S	M	L	S	M	L	S	M	L	S	M	L
				70	75	80	75	80	85	80	85	90	90	95	100	100	105	110
射出壓力	Injection Pressure		kg/cm 2	1697	1478	1299	1942	1707	1512	1860	1648	1470	1815	1629	1470	1780	1614	1471
射出率 Injection Rate		一般 General	cm 3 /sec.	253	290	330	275	313	353	379	428	480	473	527	584	525	578	635
		快速 High Speed		479	550	625	553	629	710	702	793	889	783	872	967	828	913	1002
理論射出容積	Theoretic Shot Volume		gr	1154	1325	1507	1545	1758	1985	2261	2552	2861	2861	3188	3533	3533	3895	4274
射出重量 (PS)	Injection Weight (PS)		gr	1039	1192	1356	1391	1583	1787	2035	2297	2575	2575	2869	3179	3179	3505	3847
			oz	36	42	47	49	55	63	71	80	90	90	100	111	111	123	135
鎖模部份	CLAMPING UNIT		上下肘節 VERTICAL TOGGLE
鎖模力	Clamping Force		Ton	420			480			550			750			850
開模行程	Clamping Stroke		mm	560			600			740			900			1000
脫模行程	Ejector Stroke		mm	180			180			230			320			320
支柱內距	Space Between Tie Bar		mm	655 × 655			720 × 720			820 × 820			920 × 920			1060 ×1060
夾模厚度	Mold Thickness		mm	250-750			250-850			300-900			350-1050			350-1100
動力部份	POWER UNIT
電機馬達 Pump Motor		一般 General	HP(KW)	50(37)			60(45)			75(60)			100(75)			120(90)
		快速 High Speed		75(60)			100(75)			120(90)			150(112)			150(112)
電熱容量	Heater Capacity		KW	16.7			21.6			27.2			33			37.8
泵浦壓力	Pump Pressure		kg/cm 2	140			140			140			140			140
溫度控制	Thermo Control		point	5			5			5			6			7
寸法	MEASUREMENTS
機械尺寸	Machine Size (L×W×H)		m	7.5×1.8×2.4			7.8×1.9×2.4			8.0×2.1×2.4			9.5×2.2×2.4			10.5×2.4×2.5
機械重量	Machine Weight		kg	14000			18000			25750			32000			37000
油箱容量	Tank Capacity		l	900			1000			1100			1200			1400
High pressure /High speed injection molding machine series have multiple selection by molding parts. 高壓高速機種視成品而定有多種選擇

V Series (Vertical Toggle System)
