APPLICATIONS
Logisitcs, Courier, Food Packaging, Electronic Product, Home Applicance, Other Daily Necessity Packaging Boxes
Operating System
- Production Management Software
- Remote Management System
- Ordering Set-up Function
- Intelligent Graphical User Interface
- Real-Time Information Dashboard
- Optimized Quality Management
- Downtime Information Processing
- Customized Functional Reports
-
Computer Interface Control System
Centralized control system, ensuring synchronized operation and status updates for each unit. -
Intelligent Graphical User Interface
Operator can efficiently access information and navigate seamlessly, with the flexibility to switch between various box-type production modules.
-
Ordering Set-Up Function
Adopting simple graphical user interface, the system automatically interprets the relevant functional parameters of each unit, eliminating the necessity for manual repetitive adjustments.
Feeder Unit
- The Sun Automation feeding system, capable of adapting to various conditions of corrugated sheet.
- Sunrise's vacuum system enhances the flexibility tolerance of corrugated sheets, minimizing feeding challenges resulting from variations in inconsistent cardboard quality, such as titling or shifting issues.
-
Suitable for cardboard sheets with a thickness range of 1.5~9mm (AB-E flute), it accommodates to a variety of production requirements, including different thicknesses of cardboard sheets feeding.
-
Connect to the computer system for preconfiguring corrugated sheet types and dimensions, allowing for automatic adjustments in sheet feeding distance, gap between feed rolls and stopper positions.
-
Maximize stroke extensions automatically adjusted feeding mechanism to minimize damage to the cardboard sheets.
-
工-Beam Steel Structure
Minimize operational vibrations.
Ensure stability throughout the feeding process.
Improve the precision of the feeding mechanism.
-
Automatic Cardboard Sheet Feeding with Double-Sided Squaring
The front stop and side guide lateral movement utilize mechanisms such as linear guides and ball screws, ensuring a stable and precision in cardboard feeding.
-
Lead Edge Feeding with Adjustable Vacuum System
Sun Automation lead edge feeding system, in conjunction with Sunrise's designed vacuum system, enhances adaptability to varying qualities of cardboard sheets.
Printer Unit
-
The “RETURN” function with automatic restoration for precise print positioning, enhances machine efficiency and significantly reduces waste production.
- The vacuum transfer device minimizes displacement of print dots, allowing for adjustable gaps between the cardboard sheet and printing plate to achieve the state of “kiss-touch.” This ensures high print quality for both print dots and full-page printing.
- Doctor blade chamber inking device delivers a consistent ink volume during both high and low-speed rotations, guaranteeing clarity in print dots, fine text and even full-page printing.
-
Chamber blade inking device offers easy maintenance, minimal ink consumption, short cleaning time and high system stability.
- Utilizing doctor chamber blade device effortlessly keeps the anilox clean and its surface moist, prolonging the lifespan of the anilox.
- Pneumatically controlled anilox ink transferring timming
- One-press quick ink washing system
-
Rubber Wiper Inking System
Simple structure, easy to maintain.Cost-effective ink supply system. -
__24A08S41XR.png)
Chambered Doctor Blade Ink Distributing System (Optional)
Chambered doctor blade system ensures stable print quality and ink consistency in high and low-speed operations. The optional quick-change blade system allows replacement in under one minute. -
Quick-lock Printing Plate Feature (Optional)
Quick printing plate replacement system allows for tool-free disassembly and installation of plates, effectively reducing order changeover time.
-
One Press "RETURN" Feature
Following a required pause or shutdown, simply press “RETURN” to resume production without the need for additional adjustments.
-
__24A08ySUrA.png)
Automatic Ink Shortage Detection System
To protect the anilox roll from damage caused by insufficient ink, the system will activate an alarm notification upon detecting an ink shortage. -
__24A08hfDAX.png)
Auto Ink Washing System
User-friendly interface equipped with a one-press automated quick ink washing system to simplify the procedural workflow.
Slotter Unit
-
The ball screw mechanism facilitates the lateral movement of the cylindrical shaft and linkage plates.
- Independenet slotting knife and creaser units design allowing for rapid, accurate, and high-speed control operations.
- The multi-axis slotting design, incorporating additional cardboard support shaft mechanism, improves stability and precision in cardboard transportation.
- Upon entering cardboard box dimensions needed, the machine automatically interprets slotting knife movement positions, simplifying operations and meeting production requirements.
- Achieving pre-creasing forced strengthened and enhanced creasing strength.
-
__24A08mZvIW.png)
Durable Slotting Mechanism
Durable slotting mechanism design, the slotting knife holder lateral movement by the linear guideway and ball screw to ensure a smooth move to make the slotting and creasing more flexible and precise.
-
Slotting Unit Mechanism
The independent pre-creaser, creaser, front and rear slot knives, along with cardboard support shafts enhance stability during transport and improve the efficiency of slotting and creasing processes.
-
Cut-off Slitting Knife
The cut-off edge-trimming knife prevents the accumulation of scraps and dust, ensuring precise slotting accuracy.
